| Daya Keluar | 2400VA / 1440W |
| Voltase Masuk | - Voltage : 220/230/240 VAC
- Acceptable Voltage Range :
- 170 – 280 VAC (UPS mode)
- 90 – 280 VAC (INV. Mode)
- Frequency Range : 60Hz or 50 Hz (auto sensing)
|
| Voltase Keluar | - AC Voltage Regulation (Batt. Mode) : }10%
- Frequency Range (Batt. Mode) : 60 Hz or 50 Hz }1 Hz
- Transfer Time : 20 ms typical
- Waveform (Batt. Mode) : Simulated Sine Wave
|
| Baterai | - Battery Voltage : 24 VDC
- Low Battery Alarm Voltage : 20.4 VDC ± 2%
- Overcharge Protection : 30.0 VDC ± 2%
|
| Dimensi Produk | - 293 X 231.5 X 82.5 mm (D x W x H)
|
| Berat Produk | 2.55 kg |
| Lain-lain | - AC Charger
- Constant Current Charge Voltage : 28.6 VDC ± 2%
- Floating Charge Voltage : 27.4 VDC ± 2%
- Maximum Charge Current : 10 A or 20 A
- Solar Charger :
- Maximum PV Array Open Circuit Voltage : 60 VDC
- Operating Voltage Range : 30-32 VDC
- Maximum Solar Charge Current : 30A
- Protection :
- Full Protection : Overload, and short circuit protection
- Indicator :
- Line Mode : Green lighting
- Battery Mode : Yellow lighting
- Low Battery : Yellow flashing every 2 seconds
- Shutdown Mode : Yellow flashing every 5 seconds
- Charging Mode at Power On : Green flashing every 2 seconds
- Charging Mode at Power Off : Green flashing every 5 seconds
- Overload : Red flashing for 0.5 sec. every second
- Overcharging : Red flashing every 5 seconds
- Fault : Red lighting
- Alarm
- Low Battery : Sounding every 2 second
- Overload : Sounding every 0.5 second
- Overcharging : Continuously sounding for 30 minutes, then shutdown
- Fault : Continuously sounding for 30 minutes, then shutdown
- Operation Environment :
- Storage Temperature : -15Ž to 50Ž
|
