Technical Information :
- Phase: Single phase with ground;
- Capacity: 3000 VA / 2700 W;
- Nominal Voltage: 100/110/115/120/127VAC or 200/208/220/230/240VAC;
- Input Voltage Range: 55-150 VAC or 110-300 VAC (Based on load at 50%), 85-140VAC or 160-280VAC (Based on load at 100%);
- Frequency Range: 40 Hz ~ 70 Hz; Power Factor: ≧ 0.99 @ Nominall Voltage (100% load);
- THDI: ≦ 5% @ nominal input voltage;
- Output Voltage: 100/110/115/120/127VAC or 200/208/220/230/240VAC;
- Voltage Regulation: ± 1 %;
- Frequency Range (Synchronized Range): 47~ 53 Hz or 57 ~ 63 Hz;
- Frequency Range (Batt. Mode): 50 Hz ± 0.1Hz or 60Hz ± 0.1Hz
- D x W x H (mm): 630 x 438 x 88
