Technical Information :
Daya Keluar: 1000VA/800W
Voltase Masuk:
Voltage Range :
– Low Line Transfer : 160/140/120/110VAC ±5% or 80/70/60/50VAC ±5% #1
– Low Line Comeback : 168/148/128/118VAC ±5% or 84/74/64/54VAC ±5% #1
– High Line Transfer : 300VAC ±5% or 150VAC ±5%
– High Line Comeback : 290VAC ±5% or 145VAC ±5%
Frequency Range : 40-70Hz (Auto Sensing)
Voltase Keluar
Output Voltage : 110/115/120/127VAC or 208/220/230/240VAC
Frequency Range :
– Synchronized Range : 47-53Hz or 57-63Hz
– Battery Mode : 50Hz ¡À0.2Hz or 60Hz ¡À0.2Hz
Current Crest Ratio : 3:1
Harmonic Distortion :
– Linear Load : 3% THD
– Non-Linear Load : 6% THD
Transfer Time :
– AC Mode to Battery Mode : Zero
– Inverter to Bypass : 4ms (Typical)
– Waveform (Battery Mode) : Pure Sinewave
Baterai
Standard Model :
– Battery Type : 12V9AH
– Numbers : 2
– Typical Recharge Time : 9 hours recover to 90% capacit
– Charging Current (max.) : 1A
– Charging Voltage : 27.4VDC ±1%
Long-Run Model :
– Battery Type : Depending on applications
– Numbers : 2
– Charging Current (max.) : 1A/5A
– Charging Voltage : 27.4VDC ±1%
Indicators :
– LCD Panel : UPS Status, Load Level, Battery Level, Input/Output Voltage, Discharge Timer, Fault Conditions
Alarm :
– Battery Model : Sounding every 4 seconds
– Low Battery : Sounding every seconds
– Overload : Sounding twice every seconds
– Fault : Continuously sounding
Dimensi 397 × 145 × 220mm
Lain-lain
Humidity : 20-90% Relative Humidity @ 0-40°C (Non-Condensing)
Noise Level : Less than 45dB @ 1 Meter
