Technical Information :
- Nominal Voltage: 220V.
- Threshold Voltage: 208/220/230/240VAC.
- Sofa: 1-phase (2-wire + ground wire).
- Nominal Frequency: 46-54Hz or 56-64Hz.
- Power Factor: At Nominal Voltage 0.99 (100% load).
- Capacity: 10KVA/8kW.
- Voltage: 220VAC.
- Wave: True sine wave power in every state and is not dependent on the amount of remaining battery power.
- Frequency: Synchronized with the input 50Hz or 60Hz.
- Efficiency: 93% (grid mode), 91% (battery mode)
- Battery Type: 12 VDC / x20 9Ah, Sealed, no maintenance, long life of 3 years.
- Time To Save Electricity: 5 minutes with 100% load 10 minutes with 50% load.
- Dashboard: Button start, off alarm, power off button.
- LED Status Display: Grid mode, battery mode, Bypass mode, load capacity, battery capacity, damaged status.
- The Web Of Communication: RS232, intelligent slot, RJJ45.
- Dimensions (WxDxH/mm): 442x190x688.
